POWERFUL MOTOR
The body design for rear wheels’ power transmission with AC motor power. Maximum traction power up to 6 tons using electronic motor from 2.6 to 4.9 kilowatts, alleviating the problem of heavy product transport to a steep slope.
![](upload/jBJTaseTm20191017144557.jpg)
STRONG AND DURABLE
Special gear system which allows for the highest efficiency in movement, reduces motor work load, extends the operating life of motor, and lowers maintenance cost.
![](upload/PM5pnJj3120191017144557.jpg)
EASY TO USE AND CONVENIENT
Innovative design for spacious and comfortable operator’s compartment that supports all operating postures, reducing fatigue from long daily operations.
SPECIFICATION
Models | CBT4 | CBT6 | CBTY4 | ||
---|---|---|---|---|---|
Engine Type | Electric | ||||
Operator Position | Sit-down | Sit-down | Stand-up | ||
Maximum Drawbar Pull | 3 min. ratings | kgf | 400 | 450 | 400 |
Towed Weight | 60 min. ratings | kg | 4000 | 6000 | 4000 |
Overall Width | mm | 965 | 965 | 965 | |
Turning Radius (outside) | mm | 1775 | 1775 | 1600 | |
Overall Height | mm | 1250 | 1250 | 1185 | |
Overall Length | w/ Hitch | mm | 2020 | 2020 | 1755 |
w/ o Hitch | mm | 1880 | 1880 | 1615 | |
Voltage/Capacity | Min | V/Ah | 48/210 | 48/280 | 48/160 |
Max | V/Ah | 48/280 | 48/370 | 48/250 | |
Electric Motors | Drive | kW | 2.6 | 4.9 | 2.6 |
Control Type | Transistor Chopper |
