OVERVIEW
The series of engine not more than 8 tons that Toyota has designed by the special engineering team suitable for heavy industries. Focusing on maximum durability for every heavy workload, but fit it in the compact & precise body that provides more flexible operation in any work space limitation compared to the same series of other brands. With our unique innovative functions of safety including SAS,OPS and speed control system as well as other functions installed in this series, it will provide the most comfortable and highest efficiency during forklift operation. It is well recognized from customers all around the world that our Toyota series is the no. 1 in engine forklift


THE MOST POWERFUL ENGINE
The highest lifting power with a selective engines from 3,700 cc to 5,200 cc which can be considered as the best forklift in the range from 3.5 to 8 tons. The forklifts are able to operate heavy loading for longer running hours continuously and can help settle any problems against the heavy loading operation easily.

SYSTEM OF ACTIVE STABILITY (SAS)
Safety innovation that controls the balance movement of forklifts when turning and lifting to ensure the highest efficiency. Meanwhile, there is a function of speed control for lifting the forks and its angle automatically to enhance the highest efficiency and productivity.

ACCESSIBLE IN ALL WORKSITES
Focusing on smaller body than other fuel forklift trucks in the market to allow easy access in the limited working areas with the driving support function that makes the forklift trucks more flexible and convenient to use.
SPECIFICATION
Models | 8FD35N 8FG35N |
8FD40N 8FG40N |
8FD45N 8FG45N |
8FD50N 8FG50N |
8FD60N 8FG60N |
8FD70N 8FG70N |
8FD80N 8FG80N |
|
---|---|---|---|---|---|---|---|---|
Engine Type | Diesel / Gasoline | |||||||
Load Capacity | kg | 3500 | 4000 | 4500 | 5000 | 6000 | 7000 | 8000 |
Load Center | mm | 600 | 600 | 600 | 600 | 600 | 600 | 600 |
Overall Width | mm | 1350 | 1350 | 1450 | 1450 | 1965 | 1965 | 1965 |
Turning Radius (outside) | mm | 2610 | 2660 | 2750 | 2810 | 3230 | 3280 | 3320 |
Overhead Guard Height | mm | 2210 | 2210 | 2300 | 2300 | 2310 | 2310 | 2310 |
Length to Fork Face | mm | 2925 | 2980 | 3110 | 3170 | 3490 | 3545 | 3590 |
